Thread Locker Sealant threadlocking sealant
MXBON Thread lockers are single-component, self-curing adhesives that completely fill the gaps between threads. They can replace spring washers, double nuts, and other mechanical fastening devices, thereby simplifying the product design. They also prevent screw fasteners from corroding, seizing, loosening, and leaking, consequently reducing maintenance time. They provide a permanent guarantee of screw assembly safety, enhancing the sturdiness of machinery.
Usage
- Removal: High-strength Thread Lockers can be disassembled by using either heat application or increased torque.
- Cleaning: Prior to the application, ensure the bonding area is clean. Use a cloth or steel brush to remove any debris.
- If oil residue is present, it must be removed.
- Blind Holes: For blind holes, it is more appropriate to apply the adhesive within the hole.
- Long Joints: In the case of long joints, apply adhesive to both the screw and the interior of the hole.
- Accelerating Cure: The curing process can be expedited by using the MXBON activator.
Lock in Reliability with MXBON Thread Locker Sealant
Characteristics
-
11222
Low strength, thixotropic
Lock and seal for M6 or smaller screws.
Removable. -
11242
Medium strength, general-purpose, thixotropic
Lock & seal for M20 or smaller screws.
Good for electroplating surface.
Removable. -
11243
Medium strength, oil tolerance, thixotropic
Lock & seal for M20 or smaller screws.
Suitable for lightly greased surfaces and passive substrates such as, stainless steel & electroplating surface.
Removable. -
11248
Medium strength, wax consistency
Lock & seal for M20 or smaller screws.
Semi solid stick form is incredibly convenient and portable.
Suitable for lightly greased surfaces and passive substrates such as, stainless steel & electroplating surface.
Removable. -
11268
High strength, wax consistency
Lock & seal for M20 or smaller screws.
Semi solid stick form is incredibly convenient and portable.
Suitable for lightly greased surfaces and passive substrates such as, stainless steel & electroplating surface.
Removable. -
11262
High strength, high lubricity, thixotropic
Lock & seal for M20 or smaller screws for permanent.
Excellent rust and corrosion resistance in harsh environments. -
11263
High strength, chemical resistant, fast curing, oil tolerance
Lock & seal for M25 or smaller screws.
Suitable for lightly greased surfaces and passive substrates such as, stainless steel & electroplating surface. -
11271
High strength, low viscosity, general-purpose
Lock & seal for M25 or smaller screws for permanent.
-
11272
High strength, thixotropic, heat resistance
Heat resistance up to 230°C.
Lock & seal for M36 or smaller screws for permanent. -
11277
High strength, high viscosity
Excellent chemical resistance, prevents rusting and corrosion of screws.
Lock & seal for M36 or smaller screws for permanent. -
11290
Medium to high strength, penetration type
Lock & seal for M2~M12 screws after assembly, effective for sealing micro-pores on weld seams and castings.
Prevents rusting and corrosion of screws. -
112701
High strength, for passivated materials
Excellent heat and oil resistance.
Specialized adhesive for Passivated Materials.
Lock & seal for M20 or smaller screws.
Technical Information
| Item No. | Appearance | Fluorescence |
Viscosity mPa.s |
Breakaway N-m (IB-in) |
Prevail N-m (IB-in) |
Working Temp. °C |
Curing Time | NSF | |
|---|---|---|---|---|---|---|---|---|---|
| Fixture Time | Fully Cured | ||||||||
| 11222 | Purple | 900–1,500 Thixotropic |
6 (52.8) |
4 (35) |
-54°C–150°C | 15min | 24hrs | ||
| 11242 | Blue | 900–1,400 Thixotropic |
8-19 (70-167) |
3-7 (26-62) |
-54°C–150°C | 5min | 24hrs | ||
| 11243 | Blue | 1,300–3,000 Thixotropic |
26 (229) |
5 (44) |
-54°C–180°C | 10min | 24hrs | ||
| 11248 | Blue | wax consistency | 23 (204) |
5 (44) |
-54°C–150°C | 5min | 24hrs | ||
| 11268 | Red | wax consistency | 10 (89) |
4 (39) |
-54°C–150°C | 5min | 24hrs | ||
| 11262 | Red | 1,200–2,400 Thixotropic |
26 (229) |
32 (282) |
-54°C–150°C | 10min | 24hrs | ||
| 11263 | Red | 400–600 | 34 (299) |
34 (299) |
-54°C–180°C | 10min | 24hrs | ||
| 11271 | Red | 400–600 | 17–40 (150–352) |
23–40 (202–352) |
-54°C–150°C | 10min | 24hrs | ||
| 11272 | Red | 4,000–15,000 Thixotropic |
34 (299) |
36 (317) |
-54°C–230°C | 30min | 24hrs | ||
| 11277 | Red | 6,000–8,000 | 32 (282) |
32 (282) |
-54°C–150°C | 30min | 24hrs | ||
| 11290 | Green | 20–55 | 10 (88) |
29 (255) |
-54°C–150°C | 20min | 24hrs | ||
| 112701 | Green | 500–900 | 26–50 (229–440) |
≧15 (≧132) |
-54°C–150°C | 10min | 24hrs | ||
